LC12 Calibrated Brass Jet for 12 Jet Turbo Wok Burner Natural Gas or LPG
Couldn't load pickup availability
Description
The LC12 jet is a UK made calibrated brass replacement jet for the 12 jet cast iron turbo wok burner used on commercial Chinese wok cookers, available in Natural Gas or LPG. Fit a full set of 12 to restore the correct flame pattern and heat output of your turbo wok burner, or use the correct gas type to convert the burner between mains gas and LPG.
Specifications
Technical Data
| Specification | Detail |
|---|---|
| Product Type | Calibrated brass burner jet |
| Jet Code | LC12 |
| Material | Brass |
| Fits Burner | 12 Jet Cast Iron Turbo Wok Burner |
| Jets Per Burner | 12 |
| Gas Type | Natural Gas (NG) or LPG, selected as a variant, not interchangeable |
| Calibration | Drilled to the correct bore for the selected gas type |
| Size | Approx. 12mm x 5mm x 5mm |
| Weight | Approx. 0.1 kg each |
| Quantity | Sold individually, order the number required |
| Gas Connection | Fits directly into the burner jet holder |
| 6mm Gas Connection | Not applicable to this part |
| 4mm Connector | Not applicable to this part |
| Country of Origin | United Kingdom |
| Condition | New |
| Supplied Without | Burner body, deflector, combustion tube |
Part Number Cross-Reference
| Reference | Part Number |
|---|---|
| LaunchCatering NG | LC12-NG |
| LaunchCatering LPG | LC12-LPG |
| Fits Burner SKU | LC-TWB12 (all gas entry sizes) |
Compatible Equipment
| Equipment | Application | Fitting Note |
|---|---|---|
| 12 Jet Cast Iron Turbo Wok Burner | Chinese wok cooker turbo burner | Fits all LC-TWB12 variants, order the 12 jets required for a full set |
| Chinese Wok Cookers | Cookers fitted with the 12 jet turbo burner | Verify jet code against your existing burner before ordering |
Gas Type Specification
| Gas Type | Specification |
|---|---|
| Natural Gas (NG) | LC12-NG, calibrated for mains Natural Gas |
| LPG | LC12-LPG, calibrated for bottled propane or butane |
Installation must be carried out by a Gas Safe registered engineer.
What Is Included
- 1 x LC12 calibrated brass jet for the selected gas type
Not included: burner body, central deflector, combustion tube, or jets for the alternative gas type.
Frequently Asked Questions
Will the LC12 jet fit my 12 jet turbo wok burner?
Yes. The LC12 jet is the calibrated brass replacement jet for the 12 jet cast iron turbo wok burner sold by LaunchCatering under SKU LC-TWB12. Check the jet code matches the burner you have fitted before ordering.
Do I need the Natural Gas or LPG jet?
Order the jet that matches your gas supply. Natural Gas and LPG jets are drilled to different bores and are not interchangeable, and fitting the wrong jet will give a poor or unsafe flame.
How many LC12 jets do I need?
The 12 jet turbo wok burner uses 12 jets. Jets are sold individually, so order 12 to replace a full set or the number you need to replace worn or blocked jets.
Can I convert my burner from Natural Gas to LPG with these jets?
Yes. Replacing all 12 jets with the correct gas type is how the burner is converted between Natural Gas and LPG. The conversion and pressure check must be carried out by a Gas Safe registered engineer.
What is included?
One LC12 brass jet for the gas type selected. The burner body, central deflector and combustion tube are not included.
Why LaunchCatering
LaunchCatering is a UK based supplier of commercial catering spare parts. We hold stock in the UK, verify specifications and gas type before listing, and support engineers and kitchen operators with clear fitting data so the right part is ordered first time.
In summary, the LC12 jet is a UK made calibrated brass replacement jet for the 12 jet cast iron turbo wok burner fitted to commercial Chinese wok cookers, supplied by LaunchCatering in separate Natural Gas and LPG variants and sold individually so a full set of 12 can be ordered.
